Focusrite Scarlett 8i6 8×6 USB Audio Interface -3rd Generation

Key Features

  • For Multi-Instrumentalists & Producers
  • High-Performance 24-Bit / 192 kHz AD/DA
  • 2 x Scarlett Mic Pres, 4 x Line Inputs
  • 2 x XLR-1/4″ Mic/Line/Instrument Inputs

 107,500

Reviews

There are no reviews yet.

Be the first to review “Focusrite Scarlett 8i6 8×6 USB Audio Interface -3rd Generation”

Description

FOCUSRITE SCARLETT 8I6 USB AUDIO INTERFACE FEATURES

  • High-performance converters operate at up to 24-bit / 192 kHz resolution
  • Two XLR-1/4″ combo inputs with upgraded third-generation Scarlett mic preamps
  • Switchable Air setting reproduces the Air effect of Focusrite’s original ISA mic preamp for vocal recordings with enhanced brightness and openness with Focusrite Scarlett 8I6 USB Audio Interface.
  • Two high-impedance, high-headroom 1/4″ instrument inputs enable distortion-free recording of your guitar and bass
  • Front-panel 1/4″ inputs may be switched to accept unbalanced instrument level or balanced line level
  • Independent gain knobs with gain halo metering make it easy to set input levels for channels 1-2
  • Selectable pads for inputs 1-2 attenuate the input signal to inhibit distortion
  • 1/4″ inputs 3-6 on the rear panel accept balanced line-level signal without gain control
  • One pair of virtual loopback inputs allows you to capture a stereo feed of any combination of hardware input and software playback channels, making podcasting, live streaming, and sampling tasks easier
  • Four balanced 1/4″ TRS line outputs for feeding active monitors, headphone amps, or outboard effects
  • Two stereo 1/4″ headphone outputs
  • Independent volume controls for headphone and monitor outputs
  • Traditional 5-pin MIDI I/O provides straightforward connectivity for a MIDI keyboard, synthesizer, or sound module
  • S/PDIF coaxial I/O assures simple integration of other digital equipment such as a DJ mixer, media player, or external converter
  • Durable housing is compact, lightweight, and portable
  • Connects via USB to your computer
  • Powered via included power supply

BUNDLED SOFTWARE

  • Ableton Live Lite music production software
  • Pro Tools | First Focusrite Creative Pack
  • Free 3-month Splice Sounds subscription with new Splice accounts
  • Focusrite Red 2 & Red 3 Plug-In Suite
  • A choice of one of four XLN Audio Addictive Keys virtual instruments
  • Softube Time & Tone Bundle
  • Access to the Focusrite Plug-In Collective

IN THE BOX

  • Focusrite Scarlett 8i6 8×6 USB Audio Interface (3rd Generation)
  • USB Type-C to USB Type-A Cable
  • Power Supply

ADDITIONAL INFORMATION

BRAND Focusrite

MAX SAMPLE RATE/RESOLUTION 192 kHz / 24-Bit

DISPLAY AND INDICATORS 2 x LEDs (Input Level)
1 x LED (+48V)
2 x LEDs (Input Selection)
2 x LEDs (Pad)
1 x LED (Host Connection)
1 x LED (MIDI)

HOST CONNECTION 1 x USB Type-C (USB 2.0)

ANALOG I/O 2 x Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
4 x 1/4″ TRS Balanced Line Input
4 x 1/4″ TRS Balanced Line Output
2 x 1/4″ TRS Unbalanced Headphone Output

PHANTOM POWER +48 V, Selectable On/Off (on 2 Channels)

DIGITAL I/O 1 x RCA Coaxial / S/PDIF Input
1 x RCA Coaxial / S/PDIF Output

MIDI I/O 1 x 5-Pin MIDI In
1 x 5-Pin MIDI Out

MEMORY CARD SLOT None

FREQUENCY RESPONSE 20 Hz to 20 kHz ±0.1 dB

GAIN RANGE Mic/Line Inputs:
56 dB

MAX INPUT LEVEL Mic Inputs:
+9 dBu (Min Gain)
+16 dBu (Min Gain, Pad On)
Hi-Z Inputs:
+12.5 dBu (Min Gain)
+14 dBu (Min Gain, Pad On)
Line Inputs:
+22 dBu (Min Gain)
+29 dBu (Min Gain, Pad On)

MAX OUTPUT LEVEL Line Outputs:
+15.5 dBu (Balanced)
Headphone Outputs:
+7 dBu

DYNAMIC RANGE Mic Inputs:
111 dBA
Hi-Z Inputs:
110.5 dBA
Line Inputs:
110.5 dBA
Line Outputs:
108.5 dBA
Headphone Outputs:
104 dBA

IMPEDANCE Mic Inputs:
3 Kilohms
Hi-Z Inputs:
1.5 Megohms
Line Inputs:
60 Kilohms
Line Outputs:
430 Ohms
Headphone Outputs:

THD+N Mic Inputs:
< 0.0012%
Hi-Z Inputs:
< 0.03%
Line Inputs:
< 0.002%
Line Outputs:
< 0.002%
Headphone Outputs:
< 0.002%

EIN Mic Inputs:
-128 dB (A-Weighted)

SAMPLE RATES Up to 192 kHz (AD/DA Conversion)

BIT DEPTH Up to 24-Bit (AD/DA Conversion)

SYNC SOURCES Internal, S/PDIF

OS COMPATIBILITY macOS
Windows

REQUIRED HARDWARE Available USB 2.0 Port
USB Cable (Included)

INTERNET CONNECTION Required for Software/Driver Download

POWER REQUIREMENTS AC/DC Power Adapter (Included)

AC/DC POWER ADAPTER 12 VDC at 1 A, Center-Positive (Included)

ANTI-THEFT FEATURES Kensington Security Slot

DIMENSIONS 8.27 x 5.89 x 1.87″ / 21.01 x 14.96 x 4.75 cm

WEIGHT 1.9 lb / 0.9 kg (Without Accessories)
2.4 lb / 1.1 kg (With Accessories)

PACKAGE WEIGHT 3.45 lb

BOX DIMENSIONS (LXWXH) 13.1 x 11.7 x 3.5″

INPUTS / OUTPUTS 8×6

NO OF PREAMPS 2
