Description
FOCUSRITE SCARLETT 8I6 USB AUDIO INTERFACE FEATURES
- High-performance converters operate at up to 24-bit / 192 kHz resolution
- Two XLR-1/4″ combo inputs with upgraded third-generation Scarlett mic preamps
- Switchable Air setting reproduces the Air effect of Focusrite’s original ISA mic preamp for vocal recordings with enhanced brightness and openness with Focusrite Scarlett 8I6 USB Audio Interface.
- Two high-impedance, high-headroom 1/4″ instrument inputs enable distortion-free recording of your guitar and bass
- Front-panel 1/4″ inputs may be switched to accept unbalanced instrument level or balanced line level
- Independent gain knobs with gain halo metering make it easy to set input levels for channels 1-2
- Selectable pads for inputs 1-2 attenuate the input signal to inhibit distortion
- 1/4″ inputs 3-6 on the rear panel accept balanced line-level signal without gain control
- One pair of virtual loopback inputs allows you to capture a stereo feed of any combination of hardware input and software playback channels, making podcasting, live streaming, and sampling tasks easier
- Four balanced 1/4″ TRS line outputs for feeding active monitors, headphone amps, or outboard effects
- Two stereo 1/4″ headphone outputs
- Independent volume controls for headphone and monitor outputs
- Traditional 5-pin MIDI I/O provides straightforward connectivity for a MIDI keyboard, synthesizer, or sound module
- S/PDIF coaxial I/O assures simple integration of other digital equipment such as a DJ mixer, media player, or external converter
- Durable housing is compact, lightweight, and portable
- Connects via USB to your computer
- Powered via included power supply
BUNDLED SOFTWARE
- Ableton Live Lite music production software
- Pro Tools | First Focusrite Creative Pack
- Free 3-month Splice Sounds subscription with new Splice accounts
- Focusrite Red 2 & Red 3 Plug-In Suite
- A choice of one of four XLN Audio Addictive Keys virtual instruments
- Softube Time & Tone Bundle
- Access to the Focusrite Plug-In Collective
IN THE BOX
- Focusrite Scarlett 8i6 8×6 USB Audio Interface (3rd Generation)
- USB Type-C to USB Type-A Cable
- Power Supply
ADDITIONAL INFORMATION
BRAND Focusrite
MAX SAMPLE RATE/RESOLUTION 192 kHz / 24-Bit
DISPLAY AND INDICATORS 2 x LEDs (Input Level)
1 x LED (+48V)
2 x LEDs (Input Selection)
2 x LEDs (Pad)
1 x LED (Host Connection)
1 x LED (MIDI)
HOST CONNECTION 1 x USB Type-C (USB 2.0)
ANALOG I/O 2 x Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
4 x 1/4″ TRS Balanced Line Input
4 x 1/4″ TRS Balanced Line Output
2 x 1/4″ TRS Unbalanced Headphone Output
PHANTOM POWER +48 V, Selectable On/Off (on 2 Channels)
DIGITAL I/O 1 x RCA Coaxial / S/PDIF Input
1 x RCA Coaxial / S/PDIF Output
MIDI I/O 1 x 5-Pin MIDI In
1 x 5-Pin MIDI Out
MEMORY CARD SLOT None
FREQUENCY RESPONSE 20 Hz to 20 kHz ±0.1 dB
GAIN RANGE Mic/Line Inputs:
56 dB
MAX INPUT LEVEL Mic Inputs:
+9 dBu (Min Gain)
+16 dBu (Min Gain, Pad On)
Hi-Z Inputs:
+12.5 dBu (Min Gain)
+14 dBu (Min Gain, Pad On)
Line Inputs:
+22 dBu (Min Gain)
+29 dBu (Min Gain, Pad On)
MAX OUTPUT LEVEL Line Outputs:
+15.5 dBu (Balanced)
Headphone Outputs:
+7 dBu
DYNAMIC RANGE Mic Inputs:
111 dBA
Hi-Z Inputs:
110.5 dBA
Line Inputs:
110.5 dBA
Line Outputs:
108.5 dBA
Headphone Outputs:
104 dBA
IMPEDANCE Mic Inputs:
3 Kilohms
Hi-Z Inputs:
1.5 Megohms
Line Inputs:
60 Kilohms
Line Outputs:
430 Ohms
Headphone Outputs:
THD+N Mic Inputs:
< 0.0012%
Hi-Z Inputs:
< 0.03%
Line Inputs:
< 0.002%
Line Outputs:
< 0.002%
Headphone Outputs:
< 0.002%
EIN Mic Inputs:
-128 dB (A-Weighted)
SAMPLE RATES Up to 192 kHz (AD/DA Conversion)
BIT DEPTH Up to 24-Bit (AD/DA Conversion)
SYNC SOURCES Internal, S/PDIF
OS COMPATIBILITY macOS
Windows
REQUIRED HARDWARE Available USB 2.0 Port
USB Cable (Included)
INTERNET CONNECTION Required for Software/Driver Download
POWER REQUIREMENTS AC/DC Power Adapter (Included)
AC/DC POWER ADAPTER 12 VDC at 1 A, Center-Positive (Included)
ANTI-THEFT FEATURES Kensington Security Slot
DIMENSIONS 8.27 x 5.89 x 1.87″ / 21.01 x 14.96 x 4.75 cm
WEIGHT 1.9 lb / 0.9 kg (Without Accessories)
2.4 lb / 1.1 kg (With Accessories)
PACKAGE WEIGHT 3.45 lb
BOX DIMENSIONS (LXWXH) 13.1 x 11.7 x 3.5″
INPUTS / OUTPUTS 8×6
NO OF PREAMPS 2
